fkie_message_filters::Buffer< Inputs > Class Template Reference

Store and forward data. More...

#include <fkie_message_filters/buffer.hpp>

Inheritance diagram for fkie_message_filters::Buffer< Inputs >:

Collaboration diagram for fkie_message_filters::Buffer< Inputs >:

Public Types
using	Input = IO< Inputs... >
	Grouped input types.
using	Output = IO< Outputs... >
	Grouped output types.

Public Member Functions
	Buffer (BufferPolicy policy=BufferPolicy::Discard, std::size_t max_queue_size=1) noexcept
	Constructor.
	Buffer (const rclcpp::Node::SharedPtr &node, std::size_t max_queue_size) noexcept
	Constructor.
Connection	connect_to_sink (Sink< Outputs... > &dst) noexcept
	Connect this source to a sink.
Connection	connect_to_source (Source< Inputs... > &src) noexcept
	Connect this sink to a source.
virtual void	disconnect () noexcept override
	Disconnect from all connected sources and sinks.
void	disconnect_from_all_sinks () noexcept
	Disconnect from all connected sinks.
void	disconnect_from_all_sources () noexcept
	Disconnect from all connected sources.
bool	has_some () const noexcept
	Check if the buffer has pending data.
bool	process_one ()
	Wait for and process one data item.
template<class Rep , class Period >
bool	process_one (const std::chrono::duration< Rep, Period > &timeout)
	Wait for and process one data item.
void	reset () noexcept override
	Reset filter.
void	set_node (const rclcpp::Node::SharedPtr &node) noexcept
	Process data in a dedicated ROS callback group.
void	set_policy (BufferPolicy policy, std::size_t max_queue_size=0)
	Modify the buffer policy.
void	spin ()
	Process all data indefinitely.
void	spin_once ()
	Process pending data.
bool	wait () noexcept
	Wait for pending data.
template<class Rep , class Period >
bool	wait_for (const std::chrono::duration< Rep, Period > &timeout) noexcept
	Wait for pending data until timeout expires.

Static Public Attributes
static constexpr std::size_t	NUM_INPUTS = sizeof...(Inputs)
	Number of input arguments.
static constexpr std::size_t	NUM_OUTPUTS = sizeof...(Outputs)
	Number of output arguments.

Protected Member Functions
virtual void	receive (helpers::argument_t< Inputs >... in) override
	Process incoming data.
void	send (helpers::argument_t< Outputs >... out)
	Pass data to all connected sinks.

Detailed Description

template<class... Inputs>
class fkie_message_filters::Buffer< Inputs >

Store and forward data.

The buffer acts as a decoupler in the filter pipeline. Data can be stored and processed at a later time. The pipeline is effectively split into independent upstream and downstream parts, and it becomes possible to run the downstream data processing asynchronously. For instance, you can run computationally expensive algorithms on ROS messages in a different thread without blocking the ROS subscriber callback queue.

The buffer can be used for at least three different use cases:

1. Use the buffer as a valve
   You can toggle between the BufferPolicy::Discard and BufferPolicy::Passthru modes to selectively disable or enable data processing at specific times. This is the simplest use case without any asynchronous processing.
2. Run multiple ROS callback groups
   You can let the buffer processing happen in a dedicated ROS 2 callback group. This is the simplest way to deal with computationally expensive message processing:

   namespace mf = fkie_message_filters;

   rclcpp::Node::SharedPtr node = ...;
   mf::Buffer<M> buf1(node, 10);  // will create a callback group from node

3. Run your own thread(s) for data processing
   This is the most flexible option for advanced users. You can set up your worker threads as you desire and then call spin(), spin_once() or process_one() as you see fit.

   namespace mf = fkie_message_filters;

   mf::Subscriber<M> sub;
   mf::Buffer<mf::Subscriber<M>::Output> buffer(mf::BufferPolicy::Queue, 10);
   mf::SimpleUserFilter<mf::Subscriber<M>::Output> flt;

   std::thread t([&buffer]{ buffer.spin(); });
   flt.set_processing_function(...);
   mf::chain(sub, buffer, flt);

Member Typedef Documentation

Input

template<typename... Inputs>

using fkie_message_filters::Sink< Inputs >::Input = IO<Inputs...>

inherited

Grouped input types.

This type can be used to define sources with matching types.

Output

template<typename... Outputs>

using fkie_message_filters::Source< Outputs >::Output = IO<Outputs...>

inherited

Grouped output types.

This type can be used to define sinks with matching types.

Constructor & Destructor Documentation

Buffer() [1/2]

template<class... Inputs>

fkie_message_filters::Buffer< Inputs >::Buffer ( const rclcpp::Node::SharedPtr &  node, std::size_t  max_queue_size  )

noexcept

Constructor.

Constructs a buffer with BufferPolicy::Queue policy and data processing via ROS callbacks.

• node ROS node instance which will host a dedicated callback group for data processing
• max_queue_size the maximum number of queued data items

Exceptions

Does not throw any exceptions.

Buffer() [2/2]

template<class... Inputs>

fkie_message_filters::Buffer< Inputs >::Buffer ( BufferPolicy  policy = BufferPolicy::Discard, std::size_t  max_queue_size = 1  )

noexcept

Constructor.

• policy the buffer policy
• max_queue_size for the BufferPolicy::Queue policy, the maximum number of queued data items.

Exceptions

Does not throw any exceptions.

See also

set_policy(), set_callback_queue()

Member Function Documentation

connect_to_sink()

template<typename... Outputs>

FKIE_ML_BEGIN_ABI_NAMESPACE Connection fkie_message_filters::Source< Outputs >::connect_to_sink ( Sink< Outputs... > &  dst )

noexceptinherited

Connect this source to a sink.

Can be called multiple times to connect multiple sinks; in that case, the sinks receive data in the same order as they have been connected. This function does basically the same thing as Sink::connect_to_source(), only from the opposite point of view.

• dst the sink that is to be connected

Returns

a connection object that can be used to monitor or sever the created connection

Exceptions

Does not throw any exceptions.

connect_to_source()

template<typename... Inputs>

Connection fkie_message_filters::Sink< Inputs >::connect_to_source ( Source< Inputs... > &  src )

noexceptinherited

Connect this sink to a source.

Can be called multiple times to connect multiple sources; in that case, the sink receives data from all connected sources. This function does basically the same thing as Source::connect_to_sink(), only from the opposite point of view.

• src the source that is to be connected

Returns

a connection object that can be used to monitor or sever the created connection

Exceptions

Does not throw any exceptions.

disconnect()

FKIE_ML_BEGIN_ABI_NAMESPACE void fkie_message_filters::Filter< IO< Inputs... > , IO< Inputs... > >::disconnect ( )

overridevirtualnoexceptinherited

Disconnect from all connected sources and sinks.

Convenience function that calls disconnect_from_all_sources() and disonnect_from_all_sinks().

Exceptions

Does not throw any exceptions.

Reimplemented from fkie_message_filters::Sink< Inputs >.

disconnect_from_all_sinks()

template<typename... Outputs>

void fkie_message_filters::Source< Outputs >::disconnect_from_all_sinks ( )

noexceptinherited

Disconnect from all connected sinks.

Severs the connection to all sinks, turning the send() method into a no-op.

Exceptions

Does not throw any exceptions.

disconnect_from_all_sources()

template<typename... Inputs>

void fkie_message_filters::Sink< Inputs >::disconnect_from_all_sources ( )

noexceptinherited

Disconnect from all connected sources.

Severs the connection to all sources. The receive() method will not be called any more.

Exceptions

Does not throw any exceptions.

has_some()

template<class... Inputs>

bool fkie_message_filters::Buffer< Inputs >::has_some ( ) const

noexcept

Check if the buffer has pending data.

Return values

true	if the current policy is BufferPolicy::Queue and a subsequent call to process_one() or spin_once() will process data.
false	otherwise

Exceptions

Does not throw any exceptions.

process_one() [1/2]

template<class... Inputs>

bool fkie_message_filters::Buffer< Inputs >::process_one

(

)

Wait for and process one data item.

Return values

true	data has been processed successfully
false	either the current buffer policy is not BufferPolicy::Queue, or the policy has been changed to something other than BufferPolicy::Queue while the function was waiting, or the ROS node has been shut down.

Exceptions

Does not throw any exceptions, but will propagate uncaught exceptions from filter callbacks.

process_one() [2/2]

template<class... Inputs>

template<class Rep , class Period >

bool fkie_message_filters::Buffer< Inputs >::process_one

(

const std::chrono::duration< Rep, Period > &

timeout

)

Wait for and process one data item.

• timeout maximum duration to wait for new data if none is available

Return values

true	data has been processed successfully
false	either the current buffer policy is not BufferPolicy::Queue, or the policy has been changed to something other than BufferPolicy::Queue while the function was waiting, or time timeout expired, or the ROS node has been shut down.

Exceptions

Does not throw any exceptions, but will propagate uncaught exceptions from filter callbacks.

receive()

template<class... Inputs>

void fkie_message_filters::Buffer< Inputs >::receive ( helpers::argument_t< Inputs >...  in )

overrideprotectedvirtual

Process incoming data.

Derived classes need to override this method to handle all data that is to be consumed by the sink.

Exceptions

Depends on the implementation.

Implements fkie_message_filters::Sink< Inputs >.

reset()

template<class... Inputs>

void fkie_message_filters::Buffer< Inputs >::reset ( )

overridevirtualnoexcept

Reset filter.

If the buffer policy is BufferPolicy::Queue, this will clear the internal queue and discard all pending data. Otherwise, this function has no effect.

Exceptions

Does not throw any exceptions.

Reimplemented from fkie_message_filters::FilterBase.

send()

template<typename... Outputs>

void fkie_message_filters::Source< Outputs >::send ( helpers::argument_t< Outputs >...  out )

protectedinherited

Pass data to all connected sinks.

• out data

Exceptions

Does not throw any exceptions, but will propagate uncaught exceptions from filter callbacks.

set_node()

template<class... Inputs>

void fkie_message_filters::Buffer< Inputs >::set_node ( const rclcpp::Node::SharedPtr &  node )

noexcept

Process data in a dedicated ROS callback group.

Instead of running your own processing threads, you can use the ROS callback system to schedule data processing whenever new data arrives.

• node the ROS node or nullptr to disable ROS callbacks.

Exceptions

Does not throw any exceptions.

namespace mf = fkie_message_filters;

mf::Buffer<...> buf;
rclcpp::Node::SharedPtr node = ...;

buf.set_node(node);
rclcpp::spin(node);

set_policy()

template<class... Inputs>

void fkie_message_filters::Buffer< Inputs >::set_policy	(	BufferPolicy	policy,
		std::size_t	max_queue_size = 0
	)

Modify the buffer policy.

If the new buffer policy is not BufferPolicy::Queue, any pending call to wait(), process_one(), or spin() will return. If the buffer policy is changed to BufferPolicy::Passthru, all pending data is processed immediately before the function returns. If the buffer policy is changed to BufferPolicy::Discard, all pending data is discarded immediately.

• policy the buffer policy
• max_queue_size for the BufferPolicy::Queue policy, the maximum number of queued data items. If zero, the previously set queue size remains unchanged.

Warning

If you change the policy from BufferPolicy::Queue to BufferPolicy::Passthru and there is still a pending call to process_one(), spin_once(), or spin() in a different thread, some data might be processed in parallel or out of order when the queue is flushed.

Exceptions

Does not throw any exceptions, but will propagate uncaught exceptions from filter callbacks.

spin()

template<class... Inputs>

void fkie_message_filters::Buffer< Inputs >::spin

(

)

Process all data indefinitely.

Blocks and processes all incoming data until the buffer policy is changed to something other than BufferPolicy::Queue or the ROS node is shut down.

You can call the function from multiple threads at once, and the workload will be shared among all participating threads.

Exceptions

Does not throw any exceptions, but will propagate uncaught exceptions from filter callbacks.

See also

set_policy()

spin_once()

template<class... Inputs>

void fkie_message_filters::Buffer< Inputs >::spin_once

(

)

Process pending data.

Does nothing if the buffer policy is not BufferPolicy::Queue. The method is guaranteed to return as it will only process data which is pending at invocation time. This also means that there may be new data pending already when this method returns.

Exceptions

Does not throw any exceptions, but will propagate uncaught exceptions from filter callbacks.

wait()

template<class... Inputs>

bool fkie_message_filters::Buffer< Inputs >::wait ( )

noexcept

Wait for pending data.

Return values

true	there is data available for consumption by spin_once()
false	either the current buffer policy is not BufferPolicy::Queue, or the policy has been changed to something other than BufferPolicy::Queue while the function was waiting, or the ROS node has been shut down.

Exceptions

Does not throw any exceptions.

wait_for()

template<class... Inputs>

template<class Rep , class Period >

bool fkie_message_filters::Buffer< Inputs >::wait_for ( const std::chrono::duration< Rep, Period > &  timeout )

noexcept

Wait for pending data until timeout expires.

• timeout maximum duration to wait for new data if none is available

Return values

true	there is data available for consumption by spin_once()
false	either the current buffer policy is not BufferPolicy::Queue, or the policy has been changed to something other than BufferPolicy::Queue while the function was waiting, or the timeout expired, or the ROS node has been shut down.

Exceptions

Does not throw any exceptions.

---

The documentation for this class was generated from the following files:

• include/fkie_message_filters/buffer.hpp
• include/fkie_message_filters/buffer_impl.hpp
